Keterangan
Distance between centers : 520 mm
Max. swing over bed : 200 mm
Max. swing over carriage : 100 mm
Spindle bore : 20 mm
Spindle speeds : 170-1950 RPM
Spindle taper : MT3
Metric thread cutting : 17 / 0.25-3 mm
Range of inch thread : 17 / 8/1-48/1
Taper of tallstock sleeve : MT2
Tool post travel : 60 mm
Cross travel : 100 mm
Longitudinal travel : 500 mm
Max. travel of tallstock sleeve : 70 mm
Motor power : 220V~50Hz 550W
Measuring (L x W x H) : 1225 x 550 x 560 mm
N.W / G.W. : 130 / 140 Kg
Max. swing over bed : 200 mm
Max. swing over carriage : 100 mm
Spindle bore : 20 mm
Spindle speeds : 170-1950 RPM
Spindle taper : MT3
Metric thread cutting : 17 / 0.25-3 mm
Range of inch thread : 17 / 8/1-48/1
Taper of tallstock sleeve : MT2
Tool post travel : 60 mm
Cross travel : 100 mm
Longitudinal travel : 500 mm
Max. travel of tallstock sleeve : 70 mm
Motor power : 220V~50Hz 550W
Measuring (L x W x H) : 1225 x 550 x 560 mm
N.W / G.W. : 130 / 140 Kg
