Keterangan
Drilling Cap. : 45mm
Face Milling Cap. : 80mm
End Milling Cap. : 28mm
Motor : 1100W, 220V-50Hz
Table Size : 730x210mm
Forward and Backward Travel of Table : 170mm
Left & Right Travel of Table : 450mm
Distance from Spindle Nose to Table : 475mm
Min. Distance from Spindle Axis to Column : 260mm
Spindle Travel : 120mm
Spindle Taper : MT4
Step of Spindle Speed : 6
Range of Spindle Speed 50Hz : 95-1600 Rpm
Swivel Angle of Headstock (Horizontally) : 360°
Perpendicularly : ±45°
Face Milling Cap. : 80mm
End Milling Cap. : 28mm
Motor : 1100W, 220V-50Hz
Table Size : 730x210mm
Forward and Backward Travel of Table : 170mm
Left & Right Travel of Table : 450mm
Distance from Spindle Nose to Table : 475mm
Min. Distance from Spindle Axis to Column : 260mm
Spindle Travel : 120mm
Spindle Taper : MT4
Step of Spindle Speed : 6
Range of Spindle Speed 50Hz : 95-1600 Rpm
Swivel Angle of Headstock (Horizontally) : 360°
Perpendicularly : ±45°
