WIPRO Mesin Bubut Kombinasi MP-260

• Distance between centers : 700 mm

• Max. swing over bed : 250 mm

• Max. Drilling Capacity : 13 mm

• Max. end milling capacity : 16 mm

• Max. face milling capacity : 30 mm

• Bed width : 130 mm

• Spindle bor : 26 mm

• Spindle speeds : 115-1620 RPM

• Spindle taper : MT4

• Range of metric threads : 20/0.2-3.5 mm

• Range of inch threads : 20/56-8 TPI

• Tailstock taper : MT2

• Tailstock travel : 50 mm

• Drilling head spindle speed : 100-2500 RPM

• Drilling head motor power (ac) : 500W

• Drill head spindle taper : MT2

• Spindle Stroke : 180 mm

• Distance from spindle nose to working table : 275 mm

• Motor power : 220V~50Hz 750 W

• Measuring (L x W x H) : 1500 x 630 x 1070 mm

• N.W. / G.W. : 256 / 276 Kg
