Keterangan
Distance between centers : 700 mm
Max. swing over bed : 250 mm
Max. Drilling Capacity : 13 mm
Max. end milling capacity : 16 mm
Max. face milling capacity : 30 mm
Bed width : 130 mm
Spindle bor : 26 mm
Spindle speeds : 115-1620 RPM
Spindle taper : MT4
Range of metric threads : 20/0.2-3.5 mm
Range of inch threads : 20/56-8 TPI
Tailstock taper : MT2
Tailstock travel : 50 mm
Drilling head spindle speed : 100-2500 RPM
Drilling head motor power (ac) : 500W
Drill head spindle taper : MT2
Spindle Stroke : 180 mm
Distance from spindle nose to working table : 275 mm
Motor power : 220V~50Hz 750 W
Measuring (L x W x H) : 1500 x 630 x 1070 mm
N.W. / G.W. : 256 / 276 Kg
Max. swing over bed : 250 mm
Max. Drilling Capacity : 13 mm
Max. end milling capacity : 16 mm
Max. face milling capacity : 30 mm
Bed width : 130 mm
Spindle bor : 26 mm
Spindle speeds : 115-1620 RPM
Spindle taper : MT4
Range of metric threads : 20/0.2-3.5 mm
Range of inch threads : 20/56-8 TPI
Tailstock taper : MT2
Tailstock travel : 50 mm
Drilling head spindle speed : 100-2500 RPM
Drilling head motor power (ac) : 500W
Drill head spindle taper : MT2
Spindle Stroke : 180 mm
Distance from spindle nose to working table : 275 mm
Motor power : 220V~50Hz 750 W
Measuring (L x W x H) : 1500 x 630 x 1070 mm
N.W. / G.W. : 256 / 276 Kg
