Keterangan
Drilling Cap. : 31.5mm
Face Milling Cap. : 80mm
End Milling Cap. : 28mm
Motor : 1100W, 220V-50Hz
Table Size : 730x210mm
Forward and Backward Travel of Table : 170mm
Left & Right Travel of Table : 450mm
Distance from Spindle Nose to Table : 460mm
Min. Distance from Spindle Axis to Column : 202mm
Spindle Travel : 130mm
Spindle Taper : MT3
Step of Spindle Speed : 12
Range of Spindle Speed 50Hz : 100-2150 Rpm
Swivel Angle of Headstock (Horizontally) : 360°
Perpendicularly : Cant Swivel
Face Milling Cap. : 80mm
End Milling Cap. : 28mm
Motor : 1100W, 220V-50Hz
Table Size : 730x210mm
Forward and Backward Travel of Table : 170mm
Left & Right Travel of Table : 450mm
Distance from Spindle Nose to Table : 460mm
Min. Distance from Spindle Axis to Column : 202mm
Spindle Travel : 130mm
Spindle Taper : MT3
Step of Spindle Speed : 12
Range of Spindle Speed 50Hz : 100-2150 Rpm
Swivel Angle of Headstock (Horizontally) : 360°
Perpendicularly : Cant Swivel
